Pneumatic floating ball valve

parameter
Model ： Q671F
Unit ： 1set
Material ： 304/WCB/Customization
Brand ： HENGGONG
Immediate booking
13676761845
Prev: PNEUMATIC BALL VALVE
Next: Three way ball valve
Product details

API cast steel Floating ball valve

Cast Floating Ball Valve

Bolted bonnet,Two-piece Body,Floating Ball

Full or Reduced bore,Blowout Proof Stem

Fire safe and Anti static

Stainless steel ball

ASTM A216 WCB,A351 CF8,A351 CF8M,

A351 CF3,A351 CF3M,A351 CN7M

Standards compliance

Design and Manufacture: API 608,API 6D,BS5351

Face to face(end to end): ANSI B16.10,API 6D

Flanged connection:2"~24" to ANSI B16.5

Fire-safe: API 607,API 6FA

Butt welded end: ANSI B16.25

Test and inspection: API 598,API 6D

Major parts materials

API cast steel Floating ball valve

Cast Floating Ball Valve

Bolted bonnet,Two-piece Body,Floating Ball

Full or Reduced bore,Blowout Proof Stem

Fire safe and Anti static

Stainless steel ball

ASTM A216 WCB,A351 CF8,A351 CF8M,

A351 CF3,A351 CF3M,A351 CN7M

Standards compliance

Design and Manufacture: API 608,API 6D,BS5351

Face to face(end to end): ANSI B16.10,API 6D

Flanged connection:2"~24" to ANSI B16.5

Fire-safe: API 607,API 6FA

Butt welded end: ANSI B16.25

Test and inspection: API 598,API 6D

Major parts materials

NO

Part name

Material

NO

Part name

Material

1

Bonnet

A216-WCB

9

Gasket

PTFE

2

Nut

A194-2H

10

Packing

Graphite

3

Gasket

Graphite

11

Gland

A216-WCB

4

Bolt

A193-B7

12

Screw nail

A194-2H

5

Body

A216-WCB

13

Locating piece

Carban steel

6

Seat

PTFE

14

Ring

AISI 1566

7

Ball

A105

15

Wrench

A47-667

8

Stem

A276-410
