API/DIN/JIS Streight Weir Cast Steel Iron Industrial PTFE Rubber Liner Pneumatic NPT Thread Diaphragm Valve

Parameter
Model ： EG11F
Unit ： 1set
Material ： A105/CF8/GGG50/Customization
Brand ： HENGGONG
Immediate booking
13676761845
Prev: DIN/JIS/BS Cast Iron Wcb 304 Industrial Rubber Liner PTFE Pneumatic Diaphragm Valve
Next: API/BS/JIS/DIN Streright Stainless Steel 304 Gg25 Iron NPT Thread EPDM PTFE Adic Alkaline Clamped Diaphragm Valve
Product details

ASTM/ASME/ANSI/API/DIN/BS/JIS Diaphragm   valve
Applicable Standards:
Design & Manufacture according to :ASTM/ASME/ANSI A P I American-Standard 6D
Face to Face according to :ASME B16.10
Flange Dimensions according to :ASME B16.5
Pressure & Temperature according to :ASME B16.34
Test & Inspection according to :ASTM/ASME/ANSI A P I American-Standard 6D / ASTM/ASME/ANSI A P I American-Standard 598
Visual Inspection according to :MSS SP-55
Marking according to :MSS SP-25

Material Option:


Carbon steel

A216 Gr.WCB , WCC , WCA , etc

Low temperature steel

A352 Gr.LCB , LCC , LC1 , etc

Cr-Mo steel

A217 Gr.WC6 , WC9 , C5 , C12 , C12A , etc

Stainless Steel

A351 Gr.CF8 , CF8M , CF3 , CF3M , CF8C , etc

Alloy steel

CN7M alloy 20 , CN3M alloy 20 modified , CT15C , etc

Super duplex

A995 Gr.4A , 5A , CE8MN , CD6MN , CD3MN , etc

Aluminum bronze

B148 C95500 , C95600 , C95800 , etc

Monel

M30C , M35-1 , CZ100 , etc

Inconel

CY40 inconel 600 , etc

Hastelloy

CW2m Hastelly C4 , N12MV Hastelloy B , CW12MW Hastelloy C276 , etc

Incoloy

CU5MCuC Incoloy 825 , CW6MC Incoloy 625 , etc
